Internal volume (cuft)

26

Temp. range

+10 above ambient to +250 °C

Sensor

2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error

Set Temp. Accuracy

up to 99.9 °C: 0.1 / from 100 °C: 0.5

Control Panel

Electronic microprocessor temperature controller with auto-diagnostic system

Convection/Fan

(UF) Forced Air Fan

Fresh air

Admixture of pre-heated fresh air by electronically adjustable air flap

Programming

Multifunctional programming via menu on 8-digit alphanumeric digital display (language to be chosen via set-up):- tempering profiles of up to 40 ramps- time- and set-point dependent operation- air flap adjustable in 10 % steps

Temp. Control

Independently working, digitally adjustable electronic micro-processor overtemperature monitor TWW, protection class 3.1 (max-value for overtemperature, min-value for undertemperature). Mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature

AutoSAFETY

Additionally integrated over- and undertemperature monitor "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature

Alarm

Visual and acoustic

Interior

Easy-to-clean interior,made of stainless steel, reinforced by deep drawn ribbing with integrated and protected large-area heating on four sides

Interior Dims (WxHxD) in.

41 x 47.25 x 23.75 (UF models: d less 1.5 in. For fan)

Exterior dims (WxHxD) in.

46.75 x 63.75 x 29.5 (d +2.25 in. door handle)

Weight (lbs.)

408

Power

400 V, 3 phases, 50 Hz approx. 4800 W

Warranty

3 years
